BRITON 5720 DIN Euro Profile Sashlock Case 60mm Backset

The Briton 5720 is a DIN standard euro profile sashlock suitable for lockable doors using lever furniture to withdraw the latchbolt. It has a 60mm backset with 72mm centres and a profiled latch which is reversible. One turn of a cylinder will throw the bolt 20mm. The 5720 sashlock has been fire tested to EN 1634-1 for use on fire doors up to 1hr timber / 4hr steel when used with the appropriate intumescent kit (Briton 5000.IP).

Features

Galvanised steel lockcase with satin nickel plating for corrosion resistance
EN 1634-1 and Certifire approved when used with the appropriate intumescent kit
Reversible
Bolt through fixing holes to DIN 18251
20mm single throw bolt
Profiled latch and forend
Backset: 60mm
Centres 72mm
Quick reversible latch
Grade 316 stainless steel single piece round or square forend

20mm Forend Width
