skip to IFAM X-5 Euro Cylinder Rim Lock

IFAM X-5 Euro Cylinder Rim Lock

£21.60

(£18.00 ex VAT)

sku: IFAM-X5
  • Compatible with standard Euro profile cylinders for versatile security options
  • Designed for surface-mounted installation on timber entrance doors
  • Functions as a high-security nightlatch or auxiliary deadbolt
  • Allows for integration into existing master key suites and keyed-alike systems
  • Robust internal mechanism engineered for frequent use in domestic and commercial settings
  • Ideal for both new door installations and retrofitting existing setups

Finish

Keys Supplied: per lock ( total) total (unless ordering multiple groups)
Additional Keys are available below
Qty:

Shipping From:

When ordering multiple Keyed Alike locks, only 1 set of keys are provided as all additional locks are made to work from that key.

If ordering 4 or more keyed alike locks you can have them set up as different groups. If Required: Let us know the details in the "Specific Key Requirements" field above.

Each group of locks will then receive keys.

The IFAM X-5 Euro Cylinder Rim Lock is a technical security solution designed for use on timber doors where high levels of flexibility and reliability are required. Unlike traditional rim locks with fixed cylinders, the X-5 is specifically engineered to accommodate a Euro profile cylinder. This design allows users to select their preferred security level, including anti-snap or restricted key cylinders, while maintaining the convenience of a surface-mounted rim lock mechanism.

This lock is typically used on external doors as a primary or secondary locking point. Because it utilises a standard cylinder format, it is an excellent choice for properties requiring a single key to operate multiple different locks (master keying). The mechanism provides a secure latching or deadlocking function, depending on the cylinder and installation setup used.

Typical applications include:

  • Residential front and back doors requiring enhanced cylinder security.
  • Commercial premises where easy cylinder replacement is necessary for maintenance.
  • Retrofit projects where existing timber door hardware needs upgrading without complex morticing.

The IFAM X-5 is suitable for various door thicknesses, provided the correct cylinder length is selected. It offers a robust alternative to standard nightlatches, focusing on mechanical longevity and compatibility with modern security standards.

FAQs

The IFAM X-5 Euro Cylinder Rim Lock is designed as a universal replacement for standard rim cylinders used in most surface-mounted night latches. It is compatible with a wide range of traditional door locks that utilize a rim cylinder mechanism.

The X-5 series is engineered for enhanced security, featuring several protective measures:

  • Anti-pick pins to resist manipulation attempts.
  • Anti-drill protection to prevent forced entry via power tools.
  • A high-precision internal mechanism for long-term reliability.

Installation is simple and typically requires only a standard screwdriver. You can replace your existing cylinder by unscrewing the mounting plate on the inside of the door, swapping the cylinders, and tightening the screws back into place.

Yes, the metal connecting bar on the back of the cylinder is designed with notches, allowing you to easily cut or snap it to the required length to match the thickness of your specific door.
