ERA Vectis Lever Operated Latch & Hookbolt Split Spindle - 35/95 Centre Case

£58.90

(£49.08 ex VAT)

sku: 35-9635
  • 35mm backset with 95mm centres
  • Advanced cylinder-free multipoint locking system
  • Traditional 5-lever mortice technology for superior security
  • Reversible latch accommodates both left and right-handed doors
  • Central forged brass hookbolt with a 14mm throw
  • Split spindle operation supports lever/lever and lever/pad handles
  • Supplied with 3 durable mortice keys
  • Compatible with ERA Viscount range for suiting options
Qty:

Shipping From:

When ordering multiple Keyed Alike locks, only 1 set of keys are provided as all additional locks are made to work from that key.

If ordering 4 or more keyed alike locks you can have them set up as different groups. If Required: Let us know the details in the "Specific Key Requirements" field above.

Each group of locks will then receive keys.

tick Latch & Hookbolt

The ERA Vectis Lever Operated Latch & Hookbolt Split Spindle Centre Case is an innovative security solution that brings traditional lever technology to modern multipoint locks. By eliminating the need for a separate cylinder, the Vectis Plus system provides a robust 5-lever mechanism that is highly resistant to picking and common cylinder-related attacks.

This centre case features a 35mm backset and 95mm centres, housed within a compact 220mm by 50mm case. Its design is exceptionally versatile, featuring a reversible latch that can be easily adjusted on-site to suit either left or right-handed door configurations. The central hookbolt is forged from brass and offers a full 14mm throw, ensuring a deep and secure engagement with the door frame.

  • Backset: 35mm
  • Centres: 95mm
  • Case Height: 220mm
  • Case Width: 50mm

Operation is intuitive: lift the lever handle to engage the locking mechanisms and turn the supplied key one full rotation to lock. The split spindle design makes this case suitable for use with both lever/lever and lever/pad handle sets. For added convenience, this unit can be suited to the ERA Viscount range of mortice locks, allowing for a single-key solution throughout the property.

Part Size (mm)
centres 95
Backset 35
Case Width 50
Case Height 220
