skip to GU Secury Auto A2 1050 Multipoint Lock

GU Secury Auto A2 1050 Multipoint Lock

£195.07

(£162.56 ex VAT)

sku: GU-0061
  • GU Secury Auto A2 configuration with two auxiliary deadlocks
  • 55mm backset / 20mm faceplate: L31774, reference 6-36037-69-0-1
  • 35mm backset / 16mm faceplate: L24348
  • 45mm backset / 20mm faceplate: L24335, reference 6-28482-31-0-1
  • 45mm backset / 16mm faceplate: L24334, reference 6-29041-31-0-1
  • 92mm centres and a single-spindle Euro profile centre case
  • Faceplate length and locking-point positions depend on the exact reference

model

Keys Supplied: per lock ( total) total (unless ordering multiple groups)
Additional Keys are available below
Qty:

Shipping From:

When ordering multiple Keyed Alike locks, only 1 set of keys are provided as all additional locks are made to work from that key.

If ordering 4 or more keyed alike locks you can have them set up as different groups. If Required: Let us know the details in the "Specific Key Requirements" field above.

Each group of locks will then receive keys.

Latch & Deadbolt

This GU Secury Auto A2 range combines a latch and deadbolt centre case with two auxiliary deadlocks. Available configurations are 55mm backset with a 20mm faceplate, 35mm backset with a 16mm faceplate, and 45mm backset with either a 16mm or 20mm faceplate. All four listed configurations have 92mm centres.

Match the individual reference rather than treating the range name as a fitting dimension. These versions do not share one faceplate length, case depth or marking position. The case, faceplate, fixing positions and keeps must match the door preparation. Powered access must be specified for the exact lock reference and motor assembly.

Dimensions Image: GU Secury Auto A2 1050 Multipoint Lock
Part Min (mm) Max (mm)
centres 92 -
Backset 35 55
Body Length 1770 2285
Case Width 50 73
Case Height 195 -
Locking Point Dead Bolt 2 -
Faceplate Width 16 20
