Kaba 7104 Mechanical Digital Combination Mortice Deadlatch Backset 70mm

£138.00

(£115.00 ex VAT)

sku: L3288-89
  • Mechanical operation eliminates the need for batteries or electrical wiring
  • Automatic deadlatching ensures the door is secured immediately upon closing
  • Single-code entry provides robust keyless access control for multiple users
  • Internal thumbturn allows for immediate exit from the secure side
  • Integrated 70mm backset mortice latch fits standard door preparations
  • Heavy-duty construction suitable for high-traffic commercial or residential use

Finish

Keys Supplied: per lock ( total) total (unless ordering multiple groups)
Additional Keys are available below
Qty:

Shipping From:

When ordering multiple Keyed Alike locks, only 1 set of keys are provided as all additional locks are made to work from that key.

If ordering 4 or more keyed alike locks you can have them set up as different groups. If Required: Let us know the details in the "Specific Key Requirements" field above.

Each group of locks will then receive keys.

Weather Resistant
1 Year Guarantee

The 7104 automatically relatching format

7104 is the mortice-deadlatch choice in the compact 7100 family. It relatches when the correctly aligned door closes, unlike the manually relocked 7102/7108 deadbolts. Check the listed 70mm backset and the existing latch preparation when replacing hardware.

Fitting and setup

  • Measure the door thickness, backset and existing fixing positions against the exact model drawing.
  • Set the new code and test the outside control, inside operation and latch engagement with the door open before closing it.

Compare the access options

Product support

Part Size (mm)
width 56
Backset 70

FAQs

The 70mm backset is the distance from the edge of the door to the center of the lock's keypad or spindle. It is essential to ensure your door is prepared for a 70mm measurement, as this determines where the unit will sit on the door face and whether it will align with existing holes.

No, the Kaba 7104 is a fully mechanical digital lock. It operates entirely through manual pushbutton input and internal mechanical components, meaning you do not need to worry about wiring, power outages, or replacing batteries.

Yes, the combination can be changed to maintain security. The code is set manually via the internal mechanism of the keypad. This allows you to update the access sequence whenever necessary without needing to replace the entire unit.

The mortice deadlatch provides enhanced security by automatically deadlocking the latch bolt when the door is closed. This prevents the bolt from being retracted by external force or shimming, often referred to as 'loiding,' providing a more secure closure than a standard spring latch.
