skip to Lowe & Fletcher 1439 Cam Lock

Lowe & Fletcher 1439 Cam Lock

£14.39

(£11.99 ex VAT)

sku: 694
  • Secure cam locking mechanism for cabinets and storage units
  • Operates via a 180-degree key rotation for clear locking positions
  • Snap-fix design allows for efficient installation without threaded nuts
  • Compatible with the Lowe & Fletcher 95-97 key series
  • Square head profile suitable for a variety of furniture and equipment
  • Supplied with two keys as standard for immediate use
Qty:

Shipping From:

When ordering multiple Keyed Alike locks, only 1 set of keys are provided as all additional locks are made to work from that key.

If ordering 4 or more keyed alike locks you can have them set up as different groups. If Required: Let us know the details in the "Specific Key Requirements" field above.

Each group of locks will then receive keys.

The Lowe & Fletcher 1439 Cam Lock is a versatile locking solution designed for furniture, cabinets, and lockers. It features a robust cam mechanism that secures doors or drawers by rotating a metal arm behind a frame or into a strike plate. This model is engineered for reliability in high-use environments such as offices, schools, and retail spaces.

This lock is particularly suited for applications where a snap-in fixing is preferred over traditional threaded nut fixings, allowing for faster assembly in manufacturing environments or simplified replacement in existing units. The 180-degree movement provides a simple and effective operation for users. Typical applications include:

  • Metal office furniture and filing cabinets
  • Staff and student lockers
  • Retail display cases and storage cupboards
  • Equipment enclosures

It is frequently utilised as a direct replacement part for worn mechanisms or integrated into new furniture builds requiring a reliable, key-operated security point.

Dimensions Image: Lowe & Fletcher 1439 Cam Lock
Part Size (mm)
Head Diameter 25
Body Width 16
Body Height 19
Body Length 20
Cam Length 51

Brand

SKU

694

Box Contents

2 keys

Cam Lock

FAQs

This cam lock features a convenient snap clip fixing system. This design allows for a secure installation without the need for additional screws or threaded nuts, making it ideal for quick assembly.

The lock is supplied with two keys as standard and is available in several configurations:

  • Keyed to Differ: Each lock has its own unique key (stocked).
  • Master Keyed: Compatible with master key systems for site-wide access (stocked).
  • Keyed Alike: Multiple locks can be operated by the same key (available via special order).

The lock operates with a 180-degree anti-clockwise movement. This wide range of motion ensures that the 51mm cam fully clears the locking point for smooth operation.

The lock has a square head with a 25mm diameter. To ensure it fits your application, the body dimensions are 16mm wide, 19mm high, and 20mm long, featuring a bright chrome finish for a clean, professional appearance.
