UNION Everest 3 Point Centre Case Lock - 35.5/48

£207.60

(£173.00 ex VAT)

sku: L22174
  • Secure latch and deadbolt centre case
  • Standard 48mm centres with 35.5mm backset
  • Fully reversible latch bolt for universal handing
  • Designed for use with Euro profile cylinders
  • Lift-lever operation for mechanical engagement
  • Robust 190mm x 65mm case dimensions
  • Supports split spindle configurations
Qty:

Shipping From:

When ordering multiple Keyed Alike locks, only 1 set of keys are provided as all additional locks are made to work from that key.

If ordering 4 or more keyed alike locks you can have them set up as different groups. If Required: Let us know the details in the "Specific Key Requirements" field above.

Each group of locks will then receive keys.

tick Latch & Deadbolt

The UNION Everest 3 Point Centre Case Lock is a high-security replacement gearbox designed for multi-point door locking systems. Often referred to as the Everest lock, this centre case incorporates both a latch and a deadbolt to provide a reliable security foundation for residential and commercial doors.

Engineered for versatility, the lock features a 35.5mm backset and 48mm centres. The case itself measures 190mm in height and 65mm in width, accompanied by a 30mm radius faceplate. One of its standout features is the reversible latch, which can be easily adjusted for left or right-handed doors by using a screwdriver in the rear of the case to push and rotate the bolt.

Key Technical Features:

  • Operation: Employs a lift-lever mechanism; lift the handle to engage the locking points and turn the cylinder once to secure.
  • Compatibility: Designed for Euro profile sash cases and compatible with split spindle setups.
  • Durability: Built with UNION's commitment to quality, ensuring long-lasting performance in high-traffic environments.
Dimensions Image: UNION Everest 3 Point Centre Case Lock - 35.5/48
Part Size (mm)
centres 48
Backset 36
Case Width 65
Case Height 190
Faceplate Width 30

FAQs

Yes, the UNION Everest centre case features a fully reversible latch bolt. You can easily adjust the handing for your specific door by using a screwdriver in the rear of the case to push and rotate the bolt.

This lock features a 35.5mm backset and 48mm centres. The main gearbox case measures 190mm high by 65mm wide, and it is fitted with a 30mm radius faceplate to match standard Everest multi-point systems.

To lock the door, you must lift the handle upwards to mechanically engage the locking points. Once the handle is lifted, turn the key in the Euro profile cylinder once to secure the deadbolt and lock the mechanism in place.

Yes, this centre case is designed to support split spindle configurations. This allows for independent operation of the internal and external handles, which is common in many residential multi-point locking setups.
